  Solar thermal technology uses the sun’s energy to generate heat. This energy is used to heat water and can also power solar cooling systems.
There are 3 main types of solar thermal collectors; Evacuated tube collectors, Glazed Flat plate collector and Unglazed collector
 The correct panel selection is important as each panel type works more efficiently at different temperature ranges. All of our panels are Solar keymarked and so are eligble for grants under the MCS equivilancy scheme.

Technology Overview

 How does solar thermal work?

Infrared radiation from the sun penetrates the panel through the top glass plate and gets trapped inside. The temperature increases as more radiation is trapped and heats the tubes inside the panel. The tubes are filled with a liquid (containing anti-freeze in the UK) which travels around a circuit from the panels to the hot water cylinder. When the heated liquid reaches the cylinder, it transfers its heat to the water in the cylinder. The liquid then continues round the circuit, repeating the process, until the desired temperature of the water in the cylinder is achieved. At this point, the pump stops and will only start again once the temperature in the cylinder drops.

Most UK homes will only need a small system of between 3-6 square meters to supplement their domestic hot water systems.
 For commercial systems in general, the system should be sized to meet the demand on the peak solar day of the year. This prevents the system stagnating when there is more heat available than required. A correctly sized solar thermal system can have an attractive ROI for commercial customers but are often overlooked due to the installation and maintenance being more involved than with PV.

We can help size a system to your needs, taking into account hot water demands, shading issues, roof area and strength, product efficiencies, desired temperature ranges and financial incentives. We will assess projects at no cost and give you an overview of options available to you, if we feel a different technology type might be more suited to your project, we will let you know.

If you are interested in solar thermal or you have a project you would like to discuss with us, please get in contact by going to our contact page or by clicking the button below.

Contact us

Wunder ALS 2510/ 2512

  The Wunder ALS is a quality manufactured flat plate solar thermal collector with a highly selective TinOx coated Aluminium absorber. Advanced laser welding techniques used in the manufacture of these panels mean that Solimpeks offer a 10-year warranty on the units​:

  • Dimensions: 1988 x 1218 x 90 mm
  • Weight: 44 kg
  • Absorber Panel:  Almeco-Tinox Highly Selective Aluminum
  • Gross Area Per Panel (m2): 2.42
  • WPeak (T) Nominal Power: 1751 W
  • ηo (Zero Loss Collector Efficiency): 0.785
  • a1 (Heat Loss Co-efficient): 3.722
  • a2 (Heat Loss Co-efficient): 0.012
  • Stagnation temperature: 203 Deg C
The ALS panels are ideal for use where high solar thermal generation per m² is required, the collector operates at medium to high temperature range. These panels are also available in two smaller sizes, please look at the datasheet for more detail of these.

Datasheet

Wunder ALS range


Wunder CLS Meander 2510

  The Wunder CLS meander is a flat plate solar thermal collector with a highly selective TinOx coated copper absorber. The serpentine fluid flow makes these panels more suitable to smaller systems. Advanced manufacturing techniques means that Solimpeks offer a 10-year warranty on the units​:

  • Dimensions: 1988 x 1218 x 90 mm
  • Weight: 44 kg
  • Absorber Panel:  Almeco-Tinox Highly Selective Copper
  • Gross Area Per Panel (m2): 2.42
  • WPeak (T) Nominal Power: 1690 W
  • ηo (Zero Loss Collector Efficiency): 0.757
  • a1 (Heat Loss Co-efficient): 3.816
  • a2 (Heat Loss Co-efficient): 0.011
  • Stagnation temperature: 203 Deg C
The CLS panels are ideal for use on domestic hot water systems. The collector operates at medium to high temperature range. These panels are also available in a smaller size, please look at the datasheet for more detail of these.

Wunder CLS meander

Datasheet

Wunder ALS 2517 Horizontal


The Wunder ALS Horizontal is a flat plate solar thermal collector with a highly selective TinOx coated Aluminium absorber. The Horizontal layout means they can fit on some otherwise unusable roof areas. Also on flat roofs these panels are much less visible from the ground tan a vertical mounted panel. Advanced manufacturing techniques means that Solimpeks offer a 10-year warranty on the units​:

  • Dimensions:  1218 x 1988 x 90 mm
  • Weight: 45 kg
  • Absorber Panel:  Almeco-Tinox Highly Selective Aluminum
  • Gross Area Per Panel (m2): 2.42
  • WPeak (T) Nominal Power: 1751 W
  • ηo (Zero Loss Collector Efficiency): 0.785
  • a1 (Heat Loss Co-efficient): 3.722
  • a2 (Heat Loss Co-efficient): 0.012
  • Stagnation temperature: 203 Deg C
The ALS Horizontal panels are ideal for use on flat roof areas and hard to use roof spaces. These panels work great for both domestic and commercial systems due to the ladder type pipe arrangement. The collector operates at medium to high temperature range. These panels are also available in a smaller size, please look at the datasheet for more detail of these.





Wunder-ALS Horizontal.Jpg
Datasheet

Wunder ALS Horizontal

Solar Accessories

   Through our partners at Solimpeks we can offer a wide range of quality Solar thermal accessories at great prices. Some of the most popular are in the attached brochures but should you need any other accessories please contact us and we will be able to help you source the right kit for your project. We can supply Pump stations, controllers, solar pipe, solar rated valves and AAV's, along with everything else you need for a well-functioning solar thermal system, all with great direct from manufacturer pricing.
​​



Solar - comp
Pumpstations
Controllers

Thermosiphon kits

Solimpeks are one of the world leaders in solar thermal Thermosiphon system production. The systems offered by Solimpeks can be modified to suit the needs of most customers and heat water as it passes through an indirect heat exchanger for built in protection and longer lifetime of the systems. There are a range of systems designed to be optimised for different project requirements.


TSM Eco
TSM Selective
